Super rugged, high-precision construction
Ram-type spindlehead for super rigidity
With a cross section of 350 x 350 mm (13.78 × 13.78 in) there's enough rigidity in the square ram-type spindlehead to handle any heavy-duty machining.
Z-axis twin ball screws + AbsoScale (Std)
The Z axis is controlled with double ball screws that drive bothsides of the ram.
A high level of straightness is achieved on the Z axis.
0.003 mm/800 mm (0.00012 in/31.50 in)
Powerful, highly accurate, and high-speed machining fully supported by slide/roller guideways
Powerful and highly accurate machining
Rationally designed combination slide/roller X-Y guideways absorb cutting vibration, and with rollers taking on the weight, movements are smooth, providing superb accuracies, positioning, and stable operations over long periods.
High-speed feedrate
Multitasking slide/roller guideways provide better
- Rapid traverse 20 m/min (X, Y axes) (787 ipm)
- Cutting feedrate 10 m/min (394 ipm)
Highlighted Specs
| Item | Unit | MCR-AF |
|---|---|---|
| Effective width between columns | mm (in) | 2,600 (102.36) |
| Table working surface | mm (in) | 2,000 × 1,500, 2,000 × 2,000 (78.74 × 59.06, 78.74 × 78.74) |
| Spindle speed | min-1 | 8,000 |
| Tool storage | tools | 24 |
| Motor | kW (hp) | 26/22 (30 min/cont) (35/30) |
| Machine size (W × D × H) |
mm (in) | 5,560 × 4,200 × 4,670, 5,560 × 5,230 × 4,670 (218.90 × 165.35 × 183.86, 218.90 × 205.91 × 183.86) |
